No Compromise silence and performance

The be quiet! Dark Power 13 750W offers 80 PLUS Titanium efficiency, virtually inaudible operation, and ATX 3.0 compliance for next-gen GPU compatibility.

Features:

• 80 PLUS Titanium efficiency (up to 95.8%)
• ATX 3.0 PSU with full support for PCIe 5.0 GPUs and GPUs with 6+2 pin connector
• Improved frameless Silent Wings fan for virtually inaudible operation
• Full-mesh front with funnel shape air inlet upholds the high air circulation abilities
• Overclocking key switches between four 12V rails and one massive 12V rail
• Active Rectifier + full bridge LLC technology provides unmatched signal stability and extremely high efficiency
• Modular cable management for maximum convenience

General data:

• Continuous power: 750 W
• Peak power: 850 W
• Form factor: Version 3.0
• Form factor EPS 12V: Version 2.92
• Modular Cable management: Yes
• Topology: Active Rectifier + Full bridge + LLC + SR + DC/DC
• Wire-free design (DC-side): Yes
• Digitally controlled: No
• Voltage (Vac): 100 - 240
• Frequency: 50 - 60 Hz
• Input current: 9 / 4.5 A
• PFC: active
• Power factor at 100% load: >0.98
• Compliant to Intel C6/C7: Yes
• Power consumption in standby: 100,000
• Operating temperature up to: 40 °C

Protection:

• OCP (over current protection): Ja
• OVP (over Voltage protection): Ja
• UVP (under Voltage protection): Ja
• SCP (short circuit protection): Ja
• OTP (over temperature protection): Ja
• OPP (over power protection): Ja
• SIP (Surge & Inrush Protection): Ja

Cables / Connectors:

• Cable management: Modular
• Sleeved cables: Yes
• Cable length to mainboard: 60 cm
• Flat cables: No
• Cable length to first connector: 60 cm
• Maximum cable length: 105 cm
• All-in-one cable (SATA/PATA/FDD): No
• No. of cables: 12
• ATX-Motherboard (20+4-pin): 1
• P8 (CPU): 1
• P4+4 (CPU): 1
• P4 (CPU): No
• 12VHPWR cable / W: 1 / 600
• PCIe 6-pin (GPU): No
• PCIe 6+2-pin (GPU): 4
• PATA: 3
• SATA: 12
• FDD (Floppy): No
• External fan connectors: No

Casing:

• Dimensions without cable: 175 x 150 x 86 mm (LxWxD)
• Weight: 1.96 kg
• Colour: black
